China Factory Custom Precision Steel Casting Forging

Product Item: Custom Steel Forging
Category: Forging
Views: 1329
Material: 20CrMnTi, 30Mn5, ASTM5140, 20MnCr5
Process : Forging + Machining
Package for Steel Forging: Multiplayer wood box/pallet, with big plastic bag inside
Lead Time :45 days for Steel Forging

You can make an inquiry about this product.
Your e-mail will not be leaked.

PRODUCT DETAIL

Product Description

Item Name	China Factory Custom Precision Steel Casting Forging
General Products Application / Service Area	Metal Parts Solution for Vehicle, Agriculturemachine, Construction Machine, transportation equipment, Valve and Pump system, Agriculture machine metal Parts, engine bracket, truck chassis bracket, gear box , gear housing , gear cover, shaft, spline shaft , pulley, flange, connection pipe, pipe, hydraulic valve , valve housing ,Fitting , flange, wheel, fly wheel, oil pump housing, starter housing, coolant pump housing, transmission shaft , transmission gear, sprocket, chains etc.
Main blank Process for Forged parts	Forging , Press
Blanks Tolerance	+/-0.3~+/-2 mm
Applicable Material	Carbon steel, Low Carbon steel, middle carbon steel, 40Cr, 20CrMnTi, 20CrNiMo etc.
Forging Blank Size /Dimensions	142 mm- 300mm or according to customer requirement
Blanks Weight	Range from 0.1kg-1000kg
Applicable Machining Process	CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling/ Tapping/ Broaching/Reaming etc.
Machining Tolerance	From 0.005mm-0.01mm-0.1mm
Machined Surface Quality	Ra 0.8-Ra3.2 according to customer requirement
Applicable Heat Treatment	Normalization , quenching and tempering, Case Hardening, Nitriding, Carbon Nitriding, Induction Quenching
Applicable Finish Surface Treatment	Shot/sand blast, polishing, Surface passivation, Primer Painting , Powder coating, ED- Coating, Chromate Plating, zinc-plate, Dacromat coating, Finish Painting,
MOQ	For forging parts : 1 Ton For Machining: 50 Pcs
Lead Time	45days from the receipt date of deposit for forging

Our Customers

Packing & Delivery

FAQ

1. Are you a manufacturer or a trading company?

We are a professional manufacturer with over 15 years’ export experience for designing and producing vehicle machinery parts.

2. How can I get some samples?

If you need, we are glad to offer you samples for free, but the new clients are expected to pay the courier cost, and the charge will be deducted from the payment for formal order.

3. Can you make forging according to our drawing?

Yes, we can make forging according to your drawing, 2D drawing, or 3D cad model. If the 3D cad model can be supplied, the development of the tooling can be more efficient. But without 3D, based on 2D drawing we can still make the samples properly approved.

4. Can you make forging based on our samples?

Yes, we can make measurement based on your samples to make drawings for tooling making.

5. What’s your quality control device in house?

We have spectrometer in house to monitor the chemical property, tensile test machine to control the mechanical property and UT Sonic as NDT checking method to control the forging detect under the surface of forging.
